10162
Apparently unsteamed in some time, the boiler had has a hydraulic test with new certification, the engine runs on air in both directions.
Some recommissioning work will be required before steaming, including attention to a leaky blower valve and blocked injector steam valve.
Stock code |
10162 |
Gauge |
3 1/2 inch |
Length/inches |
27 |
Width/inches |
6.5 |
Height/inches |
10 |
Wheel material |
cast iron |
Axlebox type |
plain bearing |
Cylinder material |
gunmetal |
Valve type |
slide |
Valve gear |
Joy |
Reverser type |
pole |
Lubricator type |
mechanical |
Boiler type |
locomotive |
Boiler construction |
silver soldered |
Boiler material |
copper |
Working pressure |
80 |
CE/UKCA mark |
n/a - non-commercial |
Year built |
2005 |
Boiler number |
VE.TP160 2005 |
Safety valve type |
spring |
Safety valve |
2 |
Fusible plug |
yes |
Whistle |
yes |
Hand pump |
1 |
Mechanical pump |
1 |
Injector |
1 |
Date out |
Feb-22 |
Hydraulic test valid to |
14-Dec-25 |
