11139
The engine turns over freely and runs on air in forwards gear after a fashion although not in reverse, requiring attention to eccentric and slide valve settings.
The boiler has had a twice working pressure hydraulic test with new certification issued.
Stock code |
11139 |
Scale |
1 1/2 inch & smaller |
Length/inches |
26 |
Width/inches |
12 |
Height/inches |
18 |
Weight/Kg |
33 |
Cylinder material |
gunmetal |
Valve type |
slide |
Valve gear |
Stephensons |
Reverser type |
pole |
Lubricator type |
mechanical |
Boiler type |
locomotive |
Boiler material |
copper |
CE/UKCA mark |
n/a - non-commercial |
Safety valve type |
Ramsbottom |
Safety valve |
2 |
Governor type |
Pickering |
Differential |
yes |
Road speed |
2 |
Mechanical pump |
1 |
Date out |
Oct-23 |
Hydraulic test valid to |
02-Apr-27 |
