12701
The boiler has had a hydraulic test with new certification issued. The regulator has no stops, so will open either way - when open there are leaks from the wet header joint and valve chest covers, which both require new gaskets, and the steam pipe unions.
The chassis runs on air in both directions.
Stock code |
12701 |
Gauge |
3 1/2 inch |
Length/inches |
27 + 18 |
Width/inches |
7 |
Height/inches |
12 |
Weight/Kg |
25+9 |
Wheel material |
cast iron |
Axlebox type |
plain bearing |
Cylinder material |
gunmetal |
Valve type |
slide |
Valve gear |
Stephensons |
Reverser type |
pole |
Boiler maker |
non-commercial |
Boiler type |
locomotive |
Boiler construction |
silver soldered |
Boiler material |
copper |
CE/UKCA mark |
n/a - non-commercial |
Year built |
unknown |
Boiler number |
N30-90-811 |
Safety valve type |
spring |
Safety valve |
1 |
Whistle |
1 |
Hand pump |
1 |
Mechanical pump |
1 |
Superheater type |
flue tube |
Superheater |
2 |
Date out |
Jun-25 |
Hydraulic test valid to |
23-Feb-29 |
